Description
| range of product | Harmony XB5 | |
|---|---|---|
| product or component type | Push-button | |
| device short name | XB5 | |
| bezel material | Plastic Dark grey plastic |
|
| head type | Standard | |
| fixing collar material | Plastic | |
| mounting diameter | 22Â mm | |
| sale per indivisible quantity | 1 | |
| shape of signaling unit head | Round | |
| type of operator | spring return | |
| operator profile | Blue flush, unmarked | |
| contacts type and composition | 1 NO | |
| contact operation | Slow-break | |
| connections – terminals | Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22…2 x 2.5 mm² without cable end conforming to EN/IEC 60947-1 |
Complementary
| height | 42Â mm | |
|---|---|---|
| width | 30Â mm | |
| depth | 52Â mm | |
| terminals description ISO n°1 | (13-14)NO | |
| net weight | 0.037Â kg | |
| resistance to high pressure washer | 7000000 Pa at 55 °C, distance : 0.1 m | |
| contacts usage | Standard contacts | |
| positive opening | Without | |
| operating travel | 2.6Â mm (NO changing electrical state) 4.3Â mm (total travel) |
|
| operating force | 3.8Â N NO changing electrical state | |
| mechanical durability | 10000000Â cycles | |
| tightening torque | 0.8…1.2 N.m conforming to EN 60947-1 |
